印度电动车CMVR认证
CMVR (Central Motor Vehicles Rules)是印度中央机动车辆法规的缩写,其标准委员会称为CMVR-TSC (CMVR-Technical Standing Committee),隶属于印度船舶、道路交通及高速公路管理局。从1991年起,CMVR法规规定机动车辆整车及其零部件,在进入印度市场前需要按照CMVR法规申请型式认证批准,测试项目包括安全与排放,认证流程包括工厂审核、型式认证及生产一致性控制。

CMVR法规整车强制性认证范围包括:两轮及三轮车、四轮乘用车及货车(M1, N1)、轻型及重型商用车(M2, M3, N2, N3)、工程设备车辆(CEV)、农用拖拉机、耕耘机、挂车、联合收割机、发动机、CNG/LPG车辆、电动车BOV、柴油/汽油发电机组。

印度CMVR法规对于电动车(Battery Operated Vehicle)有多项专项法规,根据不同的车辆类型在整车型式认证过程中需要额外针对电动车法规项目进行测试并取得证书。

另外,印度政府鼓励电动车在印度的发展,对于电动/混动车辆的技术研究、制造、发展和销售活动给予补贴并且在2019年3月8日发布FAME India Phase II(Scheme for Faster Adoption and Manufacturing of Electric Vehicles in India Phase II)补贴计划。

ATIC提供的技术服务包括CMVR法规咨询、整车及零部件测试与认证、工厂审核、FAME II补贴申请等全程一站式服务。

点击下载
认证流程
文件准备与符合性申请
制造商准备相关技术文件和申请文件
制造商提交零部件与系统符合性申请
制造商提交整车符合性申请
泰测审核技术文件与申请文件
送样与测试
泰测制订测试与送样计划
制造商将样品运送到指定印度实验室
部分测试也可以在符合条件的制造商实验室
或国内第三方实验室目击完成
泰测与印度发证机构执行测试并编写报告
颁发证书
印度发证机构审核测试报告
印度发证机构颁发证书
生产一致性审核
泰测与发证机构审核员前往
制造商工厂进行初次厂审
对于不同机动车产品执行不同周期的生产一致性审核
车辆注册上牌与后续年检
在线获取报价
注册或登陆泰测TM数字化客户平台获取认证报价、阅览超过54个国家16000种产品的认证流程、
法规原文、提交信息文件并管理您的认证项目
57ad482cd559bbcc1e0dc8042f656af2.svg
注册或登录
电动车BOV专项法规

对于电动机动车、低速电动车、混动车、混动改装套件、电动低速三轮车均有专项认证法规
Vehicles
电动机动车测试项目
功能及安全测试
电量测试
续航里程测试
电机功率
动力电池安全
适用范围:电动驱动车辆功率大于等于250W且最高车速大于等于25kmph
印度低速电动车认证
低速电动车测试项目
电机功率
最高车速
适用范围:电动驱动车辆功率小于250W且最高车速小于25kmph
印度混合动力车认证
混动车(HEV)
排放
制动性能
功率测试
通过噪音
其他专项测试
定义:混动车(HEV)是指为达到机械驱动的目的,同时使用了以下车载能量或动力源:可消耗的燃油、电能或电动储存装置,这些车辆必须通过以上专项测试并取得认证
Components
混动改装套件
车辆称重
滑行测试
排放测试
制动性能
通过噪音
驱动电机测试
电磁兼容
前照灯测试
结构与功能安全
可充放能量储存系统要求(REESS)
线束、电缆及接头
适用范围:以上要求适用于M1、M2及N1类车辆的电混合动力系统,其排放需符合BS-II或更高排放标准,仅使用汽油或者柴油,GVW不超过3500kg,之前未经改装或未使用其他替代燃料
印度低速三轮电动车认证
低速电动三轮车(载人或载物)
拍照存档
CMVR检查项
车辆称重
最高车速
车辆尺寸
轮胎
制动
回复反射装置
喇叭及喇叭安装
车辆VIN
汽车灯具及灯具安装
结构及功能安全
最大功率
轮毂
手把
动力电池安全
定义:
电动低速三轮车(载人)(E-rickshaw)是指出租使用的用于最后一英里载人的特殊用途电动三轮车辆,具体定义如下:设计载人数量不超过4人(除驾驶员外),设计行李装载不超过40kg,电机净功率不高于2000W,最高车速不高于25km/h。
电动低速三轮车(载物)(E-cart)是指出租使用的用于最后一英里载物的特殊用途电动三轮车辆,具体定义如下:设计有独立的装载车身或空间用于装载除去驾驶员外最大310kg的货物,电机净功率不高于2000W,最高车速不高于25km/h。
技术要求汇总

基于系统性的法规研究及实际项目经验我们将印度CMVR认证技术要求按照详细的车辆类别汇总如下
摩托车AIS
L1 Category - A two-wheeler with maximum speed not exceeding 45 km/h and engine capacity not exceeding 50 cc if fitted with a thermic engine or motor power not exceeding 0.5 kW if fitted with electric motor
L2 Category - A two wheeler other than L1 category
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
排放(I型、II型和III型)
Mass Emission Test  (Type I, II & III)
115 (19)(i)
2
蒸发排放(IV型)
Evaporative Emission (Type IV)
115 (19)(i)
3
OBD Stage I (BS - VI)
OBD Stage I (BS - VI)
115 (19)(i)
4
OBD Stage II (BS - VI)
OBD Stage II (BS - VI)
115 (19)(i)
5
电能消耗
Measurement of Electrical Energy
Consumption
124 (1)(27)
6
里程Method of Measuring the Range124 (1)(28)
7
净功率和30分钟最大功率Measurement of Net Power and
Maximum 30 Minute Power
124 (1)(29)
8
FTP测试FTP test-
9
照片存档
Photographs
-
10
车重
Vehicle Weighment
95
11
CMVR检查项
CMVR  Physical Verification
93 to 125
12
制动
Brake test
96 (2), (3), (4)(i)(b), 7(c), & (8)
13
制动 + CBS
Brake test + CBS (engine capacity ≤ 125 CC, Net power ≤ 11kw, power /weight ratio ≤ 0.1 kw/kg)
96 (4)(A)
14
防抱死系统
ABS: (other than "engine capacity ≤ 125 CC, Net power ≤ 11kw, power /weight ratio ≤ 0.1 kw/kg" category )
96 (4)(A)
15
车速表
Speedometer calibration
117 (1) & (2)
16
通过噪音
Pass by Noise Measurement
120 (1) & (2)
17
仪表盘标识
Tell tale symbols
124 (1)(18-A)
18
坡度
Gradeability
124(1)(23)
19
车辆识别代码
VIN
122(1)
20
喇叭安装
Horn Installation
119(1) & (2)
21
后视镜安装
Rear View Mirror Installation
125(2)
22
灯具安装
Installation requirements for Lighting &   Signaling devices
124(1)(24)(b)
23
防飞溅
Spray Suppression System - verification on drawing for < 200cc
124(1)(48)
24
轻型容器
Light Weight Container (If Fitted)
123
25
文件存档要求(技术)
Documentation
-
26
扶手
Pillion hand hold
123
27
防盗装置
Anti Theft device (Type I/II)
124(1)(44)
28
电磁兼容
EMC
124(1)(21)(ii)
29
结构与功能安全
Construction & Functional Safety
124 (1)(26)
30
零部件CMVR符合性审查
Component CMVR Clearance
-
31
型号及变型证书批准
Certification per base model/variant
-
32
文件存档要求(行政)
Documentation
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
喇叭
Horns
119(1)
2
后视镜
Rear View Mirror
125(2)(a)
3
灯具
Lighting & Light Signalling devices
124(1)(32)(ii)
4
光源(灯泡)
Automobile lamps (bulbs)
124(1)(1)(a) & (c)
(A)
卤素灯泡(单灯丝)
Halogen (Single Filament)
124(1)(1)(a) & (c)
(B)
卤素灯泡(双灯丝)
Halogen (Double Filament)
124(1)(1)(a) & (c)
(C)
白炽灯泡(单灯丝)
Incandescent (Single Filament)
124(1)(1)(a) & (c)
(D)
白炽灯泡(双灯丝)
Incandescent (Double Filament)
124(1)(1)(a) & (c)
5
制动软管(如配备)
Brake hose (if fitted)
124(1)(2)
6
制动液(如配备)
Brake fluid*  (if fitted)
124(1)(3)
7
燃油箱(金属或塑料)
Fuel tank (Metallic / Plastic)
124(1)(25) (a)(b)
8
轮毂
Wheel Rims*
124(1)(43)
9
轮胎
Tyres
95(1)
10
动力电池
Traction Batteries
124(1)(43)
11
回复发射器
Reflex Reflector
104(4)

电自印度认证
Battery Opearted Vehicle means a vehicle adapted for use upon roads and powered exclusively by traction battery installed in the vehicle
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
车重
Weighment
2(u)
2
净功率、30分钟最大功率和30分钟最高速度
Net Power, Max. 30 min power and max 30 min Speed test
2(u)
3
物理检查项
Physical Verification
2(u)
4
制动
Brakes
2(u)
5
反射器
Reflectors
2(u)
6
前 - 白色Front - White
2(u)
7
后 - 红色Rear - Red
2(u)

摩托车ARAI认证
L5 Category - A three wheeled motor vehicle with maximum speed exceeding 25 kmph andengine capacity exceeding 25 cc if fitted with a thermic engine, or motor power exceeding 0.25 kW if fitted with electric motor.
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
排放
Mass Emission
BS-IV norms
BS-VI norms
115 (17)
2
蒸发排放
Evaporative Emission
BS-IV norms
BS-VI norms
115 (17)
3
全油门性能
Full throttle performance
BS-IV norms
BS-VI norms
-
4
拍照存档
Photographs
-
5
车重
Vehicle weighment
95
6
CMVR物理检查项CMVR physical verification93 - 125
7
制动Brake96(1), (2), (3), (4)(i), (5), 7(a)/(b), (8)
96(1), (2), (3), (4)(ia), (5), 7(a)/(b), (8)
8
车速表Speedometer calibration117 (1) & (2)
9
通过噪声
Pass by noise measurement
120 (1) & (2)
10
仪表盘标识
Tell tale symbols
124 (1) (18)
11
爬坡
Gradeability
124 (1) (23)
12
车辆识别代码
VIN
122 (1)
13
喇叭安装
Horn installation
119 (1)
14
后视镜安装
Rear view mirror installation
125 (2)
125 (2) (a)
125 (2) (b)
15
灯具安装
Installation requirements for lighting & signaling devices
124 (1) (24) (a)
16
转弯半径
Turning circle diameter
98 (2)
17
转向力
Steering effort
98 (3)
18
乘员防护
Safety measures for occupants
125 (11)
19
外部突出物
External projection
124 (1) (11)
20
加速控制装置
Accelerator control system
124 (1) (15)
21
电磁兼容
Electromagnetic compatibility
124 (1) (21) (ii)
22
雨刮
Windscreen wiping system
124 (1) (39)
23
扶手
Hand hold
124 (1) (42)
24
防盗装置
Anti theft device
124 (1) (44)
25
基本型号与变型证书颁发
Certification per base model / variant
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
喇叭
Horns
119(1)
2
轮胎
Tyres
95 (1)
3
安全玻璃
Safety glass
100 (1), (2) & (3)
4
制动软管
Brake hose
124 (1) (2)
5
制动液
Brake fluid
124 (1) (3)
6
CNG减压器
CNG regulator
124 (4)
7
LPG蒸发器、减压器
LPG vaporiser/regulator
124 (4)
8
灯泡
Bulb
124 (1) (1)
9
后视镜
Rear view mirror
125 (2)
125 (2) (a)
125 (2) (b)

10
灯具
Lighting & light signalling devices
124 (1) (32) (i)
11
回复反射器
Reflex reflectors
104 (4)
12
燃油箱
Fuel tank
124 (1) (25) (a) (b)
13
雨刮
Windscreen wiper
101 (1), (2)
14
轮毂
Wheel rim
124 (1) (43

三轮车ARAI认证
L5 Category - A three wheeled motor vehicle with maximum speed exceeding 25 kmph andengine capacity exceeding 25 cc if fitted with a thermic engine, or motor power exceeding 0.25 kW if fitted with electric motor.
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
电能消耗
Measurement of Electrical Energy Consumption
124 (1)(27)
2
续航里程
Method of Measuring the Range
124 (1)(28)
3
净功率和30分钟最大功率
Measurement of Net Power and Maximum 30 Minute Power
124 (1)(29)
4
拍照存档
Photographs
-
5
车重
Vehicle weighment
95
6
CMVR物理检查项CMVR physical verification93 - 125
7
制动Brake96(1), (2), (3), (4)(i), (5), 7(a)/(b), (8)
96(1), (2), (3), (4)(ia), (5), 7(a)/(b), (8)
8
车速表Speedometer calibration117 (1) & (2)
9
通过噪声
Pass by noise measurement
120 (1) & (2)
10
仪表盘标识
Tell tale symbols
124 (1) (18)
11
爬坡
Gradeability
124 (1) (23)
12
车辆识别代码
VIN
122 (1)
13
喇叭安装
Horn installation
119 (1)
14
后视镜安装
Rear view mirror installation
125 (2)
125 (2) (a)
125 (2) (b)
15
灯具安装
Installation requirements for lighting & signaling devices
124 (1) (24) (a)
16
转弯半径
Turning circle diameter
98 (2)
17
转向力
Steering effort
98 (3)
18
乘员防护
Safety measures for occupants
125 (11)
19
外部突出物
External projection
124 (1) (11)
20
加速控制装置
Accelerator control system
124 (1) (15)
21
电磁兼容
Electromagnetic compatibility
124 (1) (21) (ii)
22
电动车结构与功能安全
Construction & functional safety test of BOV
124 (1) (26)
23
雨刮
Windscreen wiping system
124 (1) (39)
24
扶手
Hand hold
124 (1) (42)
25
防盗装置
Anti theft device
124 (1) (44)
26
型号及变型证书批准
Certification per base model/variant
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
喇叭
Horns
119(1)
2
轮胎
Tyres
95 (1)
3
安全玻璃
Safety glass
100 (1), (2) & (3)
4
制动软管
Brake hose
124 (1) (2)
5
制动液
Brake fluid
124 (1) (3)
6
灯泡
Bulb
124 (1) (1)
124 (1) (1)

7
动力电池
Traction battery
124 (1) (49)
8
后视镜
Rear view mirror
125 (2)
125 (2) (a)
125 (2) (b)

9
灯具
Lighting & light signalling devices
124 (1) (32) (i)
10
反射器
Reflex reflectors
104 (4)
11
雨刮
Windscreen wiper
101 (1), (2)
12
轮毂
Wheel rim
124 (1) (43)

三轮车印度准入
E-rickshaw - a special purpose battery operated vehicle having three wheels and intended to provide last mile connectivity for transport of passengers for hire or reward
E-cart - a special purpose battery operated vehicle having three wheels and intended to provide last mile connectivity for carrying goods for hire or reward
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
净功率、30分钟最大功率和最高速度
Net Power, Max. 30 min power and max 30 min Speed test
124 (1) Table B (5)
2
电动车结构及功能安全
Constructional & Functional Safety of battery operated vehicle
124 (1) Table B (4)
3
灯具安装
Installation requirement for lighting and light signalling devices
124 (1) Table B (3(a))
4
灯具性能
Performance requirements for lighting and light- signalling devices
124 (1) Table B (3(b))
5
后视镜安装
Rear View Mirror Installation
125 (2)(a)
6
喇叭安装Horn Installation119 (1) & (2)
7
扶手Requirements of Handholds124 (1) Table B (7)
8
制动Brakes96
9
CMVR物理检查项
CMVR Physical Verification
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
后视镜
Rear View Mirror
125 (2)(a)
2
轮胎
Tyres
95
3
轮毂
Wheel rims
124 (1) Table B (2)
4
喇叭
Horn
119 (1) & (2)
5
灯具
Automobiles lamps
124 (1) Table B (1)
6
灯泡
Bulbs
124 (1) Table B (3(b))
7
动力电池
Traction batteries used in battery operated vehicles
124 (1) Table B (6)

印度AIS
A Motor vehicle with at least four wheels used for carrying passengers.
M1 = D + 7(max passenger), M2 = D+8(min. passenger) & GVW < 5 Ton
M3 = D+8(min. passenger) & GVW > 5 Ton
Petrol / Diesel / CNG / LPG / Electric vehicles
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
排放
Mass Emission Test
115 (18)
2
OBD
On Board Diagnostics - II
115 (18)
3
SHED(蒸发排放)
SHED (Evaporative Emission)
115 (18)
4
实际驾驶排放
Real World Driving Emissions
115 (18)
5
电能消耗
Measurement of Electrical Energy Consumption
124 (1)(27)
6
里程Method of Measuring the Range124 (1)(28)
7
30分钟最大功率Measurement of Maximum 30 Minute Power124 (1)(29)
8
FTP测试FTP test115 (18)
9
净功率
Motor Power Test
124 (1)(29)
10
拍照存档
Photographs
-
11
车重
Vehicle Weighment
95
12
CMVR物理检查项
CMVR Physical Verification
93 to 125
13
制动
Brake test
96 (1), (2), (3), (4)(ii), (5), (6), (7) (a) & (8)
14
防抱死系统
Anti-lock braking systems
96 (4)(B)
15
备用轮胎轮毂
Run Flat Tyre/ Temporary use spare wheel
95(7)
16
车速表
Speedometer calibration
117 (1) & (2)
17
通过噪声
Pass by Noise Measurement
120 (1) & (2)
18
仪表盘标识
Tell tale symbols
124(1)(18)
19
坡度
Gradeability
124(1)(23)
20
车辆识别代码
VIN
122(1)
21
喇叭安装
Horn Installation
119(1) & (2)
22
后视镜安装
Rear View Mirror Installation
125(2)(c)
23
灯具安装
Installation requirements for Lighting & Signaling devices
124(1)(24)
24
转弯半径
Turning Circle Diameter
98(2)
25
转向力
Steering Effort
98(3)
26
外部突出物
External Projection
124 (1)(11)
27
护轮板
Wheel Guard
124 (1)(13)
28
轮栓、轮毂盖
Wheel Nut & Hub Cap
124 (1)(14)
29
发动机罩锁扣
Hood Latch
124 (1)(17)
30
脚踏板
Foot Control
124 (1)(45)
31
最小离地间隙
Minimum ground clearance
124 (1)(50)
32
限速装置和限速功能
SLD/SLF Fitment - For Transport Vehicles Only
118
33
其他安全特性
Additional Safety Features (As per AIS 145/ 2017)
125(9)
34
雨刮
Windscreen Wiping System
124 (1)(39)
35
电磁兼容
EMC
124(1)(21)(ii)
36
儿童约束系统
Child Restraint System
125 (7)
37
转向机构保护
Requirements for behaviour of steering mechanism of vehicle in a Head On Collison
124 (1)(5)(a),(b) & (c)
38
偏置碰
Protection of occupants in the event of an Offset Frontal Collison
124 (1)(5)(a),(b) & (c)
39
侧碰
Protection of occupants in the event of an Lateral Collison
124 (1)(6) (a),(b) & (c)
40
行人保护
Protection of Pedestrian and Other Vulnerable Road Users in the event of a collision with a motor vehicle
124 (1)(6) (a),(b) & (c)
41
加速控制装置
Acclerator Control System
124 (1)(15)
42
前照灯调节装置
Installation Requirement for Vertical Orientation of Head Lamp
124 (1)(20)
43
结构和功能安全
Construction & Functional Safety
124 (1)(26)
44
视野
Field of Vision
124 (1)(34)
45
内饰
Interior Fitting
124(1)(38)
46
保险杠
Bumper Fitment
124(1)(41)
47
除雾装置
Demisting System
124(1)(46)
48
除霜装置
Defrosting System
124(1)(46)
49
防盗装置
Protective devices against unauthorised use for M and N category vehicles - Vehicle Level
124(1)(51)
50
报警与防盗装置
Vehicle Alarm Systems and Immobilizers for M1 category, and N1 category (having GVW not more than 2 ton) - Vehicle Level
124(1)(52)




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
喇叭
Horns
119(1)
2
后视镜
Rear View Mirror
125(2)(a)
3
灯具
Lighting & Light Signalling devices
124(1)(20)(i)
4
光源(灯泡)
Automobile lamps (bulbs)
124(1)(1)(a) & (c)
(A)
卤素灯泡(单灯丝)
Halogen (Single Filament)
124(1)(1)(a) & (c)
(B)
卤素灯泡(双灯丝)
Halogen (Double Filament)
124(1)(1)(a) & (c)
(C)
白炽灯泡(单灯丝)
Incandescent (Single Filament)
124(1)(1)(a) & (c)
(D)
白炽灯泡(双灯丝)
Incandescent (Double Filament)
124(1)(1)(a) & (c)
5
制动软管(如配备)
Brake hose (if fitted)
124(1)(2)
6
制动液(如配备)
Brake fluid*  (if fitted)
124(1)(3)
7
燃油箱(金属或塑料)
Fuel tank (Metallic / Plastic)
124(1)(7) (a), 124(1)(7) (b)
8
轮毂
Wheel Rims
124(1)(43)
9
轮胎
Tyres
95(1)
10
动力电池
Traction Batteries
124(1)(43)
11
安全玻璃
Safety Glass
100 (1), (2), (3)
12
雨刮与洗涤器
Windscreen Wiper & Washing System
101 (1), (2)
13
安全带及固定点
Safety Belt & Safety Belt Anchorages
125(1) & (1A)
14
座椅、固定点及头枕
Seat, Seat Anchorages & Head Restraints
125 (5)
15
门铰链
Door Hinges
124 (1)(16)
16
门锁
Door Latches
124 (1)(16)
17
防盗装置
Protective devices against unauthorised use for M and N category vehicles - Component Level
124(1)(51)
18
车辆报警和防盗系统
Vehicle Alarm Systems and Immobilizers for M1 category, and N1 category (having GVW not more than 2 ton) - Component Level
124(1)(52)
19
智能运输系统-零部件
Intelligent Transportation Systems (ITS) - Component Level
125 (H)
20
三角警告牌
Warning Triangle
138 (4)(c)
21
自适应前照灯
Adaptive Front Lighting Systems (AFS), if
provided on motor vehicles of categories M and N.

124 (1)(53)
22
回复反射器
Reflex Reflector
104(4)
23
动力电池
Electric Power Train Vehicles – Central Motor Vehicles Rules Type Approval for Electric Power Train Vehicles
124 (1)(30)

中巴AIS认证
Category M2 - Motor Vehicle used for carriage of Passnegers comprising 9 or more seats in addition to driver and having a a mximum GVW not exceeding 5 tonnes (This list is only applicable for Vehicles with Reference Mass up to 2840 kg)
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
排放
Mass Emission Test
115 (18)
2
OBD
On Board Diagnostics - II
115 (18)
3
SHED(蒸发排放)
SHED (Evaporative Emission)
115 (18)
4
实际驾驶排放
Real World Driving Emissions
115 (18)
5
电能消耗
Measurement of Electrical Energy Consumption
124 (1)(27)
6
里程Method of Measuring the Range124 (1)(28)
7
30分钟最大功率Measurement of Maximum 30 Minute Power124 (1)(29)
8
FTP测试FTP test115 (18)
9
功率
Motor Power Test
124 (1)(29)
10
拍照存档
Photographs
-
11
车重
Vehicle Weighment
95
12
CMVR物理检查项
CMVR Physical Verification
93 to 125
13
制动
Brake test
96 (1), (2), (3), (4)(ii), (5), (6), (7) (a) & (8)
14
防抱死系统
Anti-lock braking systems
96 (4)(B)
15
车速表
Speedometer calibration
117 (1) & (2)
16
通过噪声
Pass by Noise Measurement
120 (1) & (2)
17
仪表盘标识
Tell tale symbols
124(1)(18)
18
坡度
Gradeability
124(1)(23)
19
车辆识别代码
VIN
122(1)
20
喇叭安装
Horn Installation
119(1) & (2)
21
后视镜安装
Rear View Mirror Installation
125(2)(c)
22
灯具安装
Installation requirements for Lighting & Signaling devices
124(1)(24)
23
转弯半径
Turning Circle Diameter
98(2)
24
转向力
Steering Effort
98(3)
25
外部突出物
External Projection
124 (1)(11)
26
轮栓、轮毂盖
Wheel Nut & Hub Cap
124 (1)(14)
27
限速装置和限速功能
SLD/SLF Fitment - For Transport Vehicles Only
118
28
其他安全特性
Additional Safety Features (Only Rear Parking Assist)
125(9)
29
等速油耗
Constant Speed Fuel Consumption
124 (1)(31)(b)
30
内部噪音
Interior Noise
124 (1)(40)
31
雨刮
Windscreen Wiping System
124 (1)(39)
32
电磁兼容
EMC
124(1)(21)(ii)
33
加速控制装置
Acclerator Control System
124 (1)(15)
34
前照灯调节装置
Installation Requirement for Vertical Orientation of Head Lamp
124 (1)(20)
35
结构和功能安全
Construction & Functional Safety
124 (1)(26)
36
内饰
Interior Fitting
124(1)(38)
37
防盗装置
Protective devices against unauthorised use for M and N category vehicles - Vehicle Level
124(1)(51)
38
临时驾驶室
Temporary cabin fitted on drive away chassis
125 (1-C)
39
扶手
Handhold Fitment
124 (1)(42)




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
喇叭
Horns
119(1)
2
后视镜
Rear View Mirror
125(2)(a)
3
灯具
Lighting & Light Signalling devices
124(1)(20)(i)
4
光源(灯泡)
Automobile lamps (bulbs)
124(1)(1)(a) & (c)
(A)
卤素灯泡(单灯丝)
Halogen (Single Filament)
124(1)(1)(a) & (c)
(B)
卤素灯泡(双灯丝)
Halogen (Double Filament)
124(1)(1)(a) & (c)
(C)
白炽灯泡(单灯丝)
Incandescent (Single Filament)
124(1)(1)(a) & (c)
(D)
白炽灯泡(双灯丝)
Incandescent (Double Filament)
124(1)(1)(a) & (c)
5
制动软管(如配备)
Brake hose (if fitted)
124(1)(2)
6
制动液(如配备)
Brake fluid*  (if fitted)
124(1)(3)
7
燃油箱(金属或塑料)
Fuel tank (Metallic / Plastic)
124(1)(7) (a), 124(1)(7) (b)
8
轮毂
Wheel Rims
124(1)(43)
9
轮胎
Tyres
95(1)
10
动力电池
Traction Batteries
124(1)(43)
11
安全玻璃
Safety Glass
100 (1), (2), (3)
12
雨刮与洗涤器
Windscreen Wiper & Washing System
101 (1), (2)
13
安全带及固定点
Safety Belt & Safety Belt Anchorages
125(1) & (1A)
14
座椅、固定点及头枕
Seat, Seat Anchorages & Head Restraints
125 (5)
15
门铰链
Door Hinges
124 (1)(16)
16
门锁
Door Latches
124 (1)(16)
17
防盗装置
Protective devices against unauthorised use for M and N category vehicles - Component Level
124(1)(51)
18
智能运输系统-零部件
Intelligent Transportation Systems (ITS) - Component Level
125 (H)
19
三角警告牌
Warning Triangle
138 (4)(c)
20
自适应前照灯
Adaptive Front Lighting Systems (AFS), if
provided on motor vehicles of categories M and N.

124 (1)(53)
21
回复反射器
Reflex Reflector
104(4)
22
反射条
Reflective Tape
104 (1)
23
动力电池
Electric Power Train Vehicles – Central Motor Vehicles Rules Type Approval for Electric Power Train Vehicles
124 (1)(30)

大巴AIS
M3 Category - A Motor vehicle used for carriage of passengers, comprising nine or more seats in addition to driver's seat and having a gross vehicle weight exceeding five tonnes.
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
定义
Definitions (Classification of the Vehicle) – M3
2
2
拍照存档
Photographs
-
3
CMVR物理检查项
CMVR physical verifications
93 to 125
4
车重
Vehicle weighment
95
5
制动
Brake test
96(4)
6
防抱死系统ABS Testing96 (5)(6)(7)(a)& (8)
7
通过噪音Pass by noise test120(2)
8
内部噪音Interior noise test124 (1)(40)
9
滑行测试
Coast down test
-
10
电磁兼容
Electromagnetic compatibility of motor vehicle
124(1) (21) (ii)
11
限速装置
Speed governor
118 (1)
12
加速控制装置
Accelerator control system
124(1) (15)
13
仪表盘标识
Tell tale symbols
124(1) (19)
14
灯具安装
Installation requirements for Lighting & Signaling
124(1) (20)
15
前照灯调节装置
Vertical orientation for dipped beam - head lamp
124(1) (20)
16
爬坡
Gradeability test
124(1) (23)
17
防火
Flammability requirement
124 (1) (37)
18
雨刮
Windscreen wiping system
101(2) (3)
19
扶手
Hand hold
124 (1) (42)
20
防盗
Protective devices against unauthorized use for M
124 (1) (51)
21
转弯半径
Turning circle diameter test
98(2)
22
转向力
Steering effort test
98(3)
23
车速表
Speedometer calibration
117(1)(2)
24
外部突出物
External projection test
124(11)
25
等速油耗
Constant speed fuel consumption
124(1) (31)
26
喇叭安装
Horn Installation
119(1)
27
后视镜安装
Rear View Mirror Installation
125(2)
28
车架号及发动机号刻印
Embossment of the Chassis Number & Engine
122(1)
29
反光条安装
Fitment of Reflective tape
104(1)
30
柴油机排放
Engine mass emission with particulate (diesel)
115
31
II型排放测试 (OBD II)
On-board Diagnostic System (OBD II) for Emission
115
32
自由加速测试(最大烟度)
Free acceleration test (Maximum smoke density)
115
33
发动机排放 (BS VI norms)
Engine Mass Emission (BS VI norms)
115
34
发动机功率
Engine Power test
115
35
临时驾驶室
Temporary Cabin fitted on drive away chassis
125(1-C)
36
内饰
Interior Fittings
124(38)
37
后防护
Rear Under Run Protection Device
124(1A)
38
侧防护
Vehicle Lateral Protection Side
124(1A)
39
轮栓、轮盘及轮毂罩
Wheel nuts , wheel discs & hub caps
124(14)
40
大巴车窗
Bus window retention
124(1) (12)
41
大巴车身生产商授权
Accreditation of Bus Body Builders
125C (1)
42
尺寸检查-大巴车身
Dimesnional Verification- Vehicle as per bus body
125C (1)
43
物理检查项 - 电平测试
Physical Verification- Electrical Level Tests
125C (1)
44
车身结构稳定性
Body Structure Stability (as per 6.2)
125C (1)
45
车身结构计算机模拟测试
Body Structure Strength Test using Computer (as per 6.1) (Including Joint Strength Tests)
125C (1)
46
雨刮模拟测试
Wiping Test on Mockup
101(2) (3)
47
座椅固定点
Seat Anchorage Test
AIS 023
48
内部振动
Interior Vibration
125 (C) (7)
49
内部声振粗糙度
Interior Harshness
125 (C) (7)
50
加速
Acceleration
125 (C) (7)
51
最低固有频率
Lowest Natural frequency
125 (C) (7) (a)
52
物理检查项(AIS 153)
Physical Verification (AIS 153)
125 (C) (7)
53
火灾探测报警及火灾探测灭火系统
FDAS/FDSS (vehicle level)
125 (C) (7)
54
轮椅约束系统
Wheel chair restraint system
125 (C) (7) (a)
55
应急照明系统
Emergency Lighting System
125 (C) (7)
56
电动坡
Power Operated Ramps
125 (C) (7)
57
制动及车辆稳定性
Braking Performance & Vehicle Stability Function
125 (C) (7)
58
实际驾驶排放
Real Driving Emmisions (RDE)
115
59
车辆定位跟踪系统
Vehicle Tracking System
125 H (1, 2)
60
冷却性能
Cooling Perfomance test
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
座椅、固定点及头枕
Seat, their Anchorages & Head Restraints
125 (6)
a
驾驶座椅
Driver Seat
125 (6)
b
副驾驶座椅
Co-Driver Seat
125 (6)
c
乘客座椅
Passenger Seat
125 (6)
2
门锁门铰链
Door Lock/Door rentention
124 (1)Table
3
安全玻璃
Safety Glass
100 (2)
4
后视镜(外部)
Rear view Mirror (Exterior)
125(2)
5
液压制动软管
Hydraullic Brake Hose
124 (1) (2)
6
制动液
Hydraullic Brake Fluid
124 (1) (3)
7
燃油箱
Fuel Tank
124 (1) (7)
8
安全带
Safety Belt Assemblies
125 (1)
9
安全带固定点
Safety Belt Anchorages
125 (1)
10
车窗
Window Frame
-
11
车窗固定及开启
Window Retention & release
-
12
雨刮系统及雨刮片
Windscreen Wiping System & Wiper Blade
101 (2)
13
衬料
Safety requirements of Pad Material
-
14
填料
Safety requirements of Upholstery
-
15
防火
Flammability requirement (For 22 seater above)
-
16
轮毂
Wheel Rims
124(8)
17
轮胎
Tyres
95
18
尘土雨水进入
Ingress of Dust & Rain water
-
19
车身绝缘
Safety requirements of Body Insulation
-
20
空调系统
Safety requirements of AC System
-
21
回复反射器
Reflex Reflectors
104 (4)
22
火灾探测报警系统及火灾探测灭火系统
Fire Detection & Alarm System (FDAS) & Fire detection & suppression system (FDSS) - Component level
125 (C) (7) (a)
23
喇叭
Automotive Horns
119 (1)
24
灯具
Performance Requirements for Lighting & Signaling
124 (1)
25
三角警告牌
Warning Triangles
138 (1A)
26
反射条粘贴
Fitment of reflective tape
104(1)
27
车辆定位追踪单元
Vehicle tracking Unit
125 H
28
电缆及保险丝
Electrical Cables & Fuses
-
29
端子、连接器及元件
Terminals, Connectors & Elements
-
30
电气装置及布线
Safety Requirements of electrical equipments & wiring
-
31
电路图
Type Approval of circuit diagram
-
32
导线导体
Electrical Conductor Test
-
33
照明
Illumination
-

大巴ARAI
M3 Category - A Motor vehicle used for carriage of passengers, comprising nine or more seats in addition to driver's seat and having a gross vehicle weight exceeding five tonnes.
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
定义
Definitions (Classification of the Vehicle) – M3
2
2
拍照存档
Photographs
-
3
CMVR物理检查项
CMVR physical verifications
93 to 125
4
车重
Vehicle weighment
95
5
制动
Brake test
96(4)
6
防抱死系统ABS Testing96 (5)(6)(7)(a)& (8)
7
通过噪音Pass by noise test120(2)
8
内部噪音Interior noise test124 (1)(40)
9
滑行测试
Coast down test
-
10
电磁兼容
Electromagnetic compatibility of motor vehicle
124(1) (21) (ii)
11
限速装置
Speed governor
118 (1)
12
加速控制装置
Accelerator control system
124(1) (15)
13
仪表盘标识
Tell tale symbols
124(1) (19)
14
灯具安装
Installation requirements for Lighting & Signaling
124(1) (20)
15
前照灯调节装置
Vertical orientation for dipped beam - head lamp
124(1) (20)
16
爬坡
Gradeability test
124(1) (23)
17
防火
Flammability requirement
124 (1) (37)
18
雨刮
Windscreen wiping system
101(2) (3)
19
扶手
Hand hold
124 (1) (42)
20
防盗
Protective devices against unauthorized use for M
124 (1) (51)
21
转弯半径
Turning circle diameter test
98(2)
22
转向力
Steering effort test
98(3)
23
车速表
Speedometer calibration
117(1)(2)
24
外部突出物
External projection test
124(11)
25
等速油耗
Constant speed fuel consumption
124(1) (31)
26
喇叭安装
Horn Installation
119(1)
27
后视镜安装
Rear View Mirror Installation
125(2)
28
车架号及发动机号刻印
Embossment of the Chassis Number & Engine
122(1)
29
反光条安装
Fitment of Reflective tape
104(1)
30
柴油机排放
Engine mass emission with particulate (diesel)
115
31
II型排放测试 (OBD II)
On-board Diagnostic System (OBD II) for Emission
115
32
自由加速测试(最大烟度)
Free acceleration test (Maximum smoke density)
115
33
发动机排放 (BS VI norms)
Engine Mass Emission (BS VI norms)
115
34
发动机功率
Engine Power test
115
35
临时驾驶室
Temporary Cabin fitted on drive away chassis
125(1-C)
36
内饰
Interior Fittings
124(38)
37
后防护
Rear Under Run Protection Device
124(1A)
38
侧防护
Vehicle Lateral Protection Side
124(1A)
39
轮栓、轮盘及轮毂罩
Wheel nuts , wheel discs & hub caps
124(14)
40
大巴车窗
Bus window retention
124(1) (12)
41
大巴车身生产商授权
Accreditation of Bus Body Builders
125C (1)
42
尺寸检查-大巴车身
Dimesnional Verification- Vehicle as per bus body
125C (1)
43
物理检查项 - 电平测试
Physical Verification- Electrical Level Tests
125C (1)
44
车身结构稳定性
Body Structure Stability (as per 6.2)
125C (1)
45
车身结构计算机模拟测试
Body Structure Strength Test using Computer (as per 6.1) (Including Joint Strength Tests)
125C (1)
46
雨刮模拟测试
Wiping Test on Mockup
101(2) (3)
47
座椅固定点
Seat Anchorage Test
AIS 023
48
内部振动
Interior Vibration
125 (C) (7)
49
内部声振粗糙度
Interior Harshness
125 (C) (7)
50
加速
Acceleration
125 (C) (7)
51
最低固有频率
Lowest Natural frequency
125 (C) (7) (a)
52
物理检查项(AIS 153)
Physical Verification (AIS 153)
125 (C) (7)
53
火灾探测报警及火灾探测灭火系统
FDAS/FDSS (vehicle level)
125 (C) (7)
54
轮椅约束系统
Wheel chair restraint system
125 (C) (7) (a)
55
应急照明系统
Emergency Lighting System
125 (C) (7)
56
电动坡
Power Operated Ramps
125 (C) (7)
57
制动及车辆稳定性
Braking Performance & Vehicle Stability Function
125 (C) (7)
58
实际驾驶排放
Real Driving Emmisions (RDE)
115
59
车辆定位跟踪系统
Vehicle Tracking System
125 H (1, 2)
60
CNG和LPG车辆的安全检查
Safety Checks for CNG & LPG vehicles
115 (B) (E)
61
大巴续航里程测试
Range test for buses
124(1)
62
冷却性能
Cooling Perfomance test
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
座椅、固定点及头枕
Seat, their Anchorages & Head Restraints
125 (6)
a
驾驶座椅
Driver Seat
125 (6)
b
副驾驶座椅
Co-Driver Seat
125 (6)
c
乘客座椅
Passenger Seat
125 (6)
2
门锁门铰链
Door Lock/Door rentention
124 (1)Table
3
安全玻璃
Safety Glass
100 (2)
4
后视镜(外部)
Rear view Mirror (Exterior)
125(2)
5
液压制动软管
Hydraullic Brake Hose
124 (1) (2)
6
制动液
Hydraullic Brake Fluid
124 (1) (3)
7
燃油箱
Fuel Tank
124 (1) (7)
8
安全带
Safety Belt Assemblies
125 (1)
9
安全带固定点
Safety Belt Anchorages
125 (1)
10
车窗
Window Frame
-
11
车窗固定及开启
Window Retention & release
-
12
雨刮系统及雨刮片
Windscreen Wiping System & Wiper Blade
101 (2)
13
衬料
Safety requirements of Pad Material
-
14
填料
Safety requirements of Upholstery
-
15
防火
Flammability requirement (For 22 seater above)
-
16
轮毂
Wheel Rims
124(8)
17
轮胎
Tyres
95
18
尘土雨水进入
Ingress of Dust & Rain water
-
19
车身绝缘
Safety requirements of Body Insulation
-
20
空调系统
Safety requirements of AC System
-
21
回复反射器
Reflex Reflectors
104 (4)
22
火灾探测报警系统及火灾探测灭火系统
Fire Detection & Alarm System (FDAS) & Fire detection & suppression system (FDSS) - Component level
125 (C) (7) (a)
23
喇叭
Automotive Horns
119 (1)
24
灯具
Performance Requirements for Lighting & Signaling
124 (1)
25
三角警告牌
Warning Triangles
138 (1A)
26
反射条粘贴
Fitment of reflective tape
104(1)
27
车辆定位追踪单元
Vehicle tracking Unit
125 H
28
CNG气瓶
CNG Cylinder
115 B (Item E)
29
CNG气瓶阀
CNG Cylinder Valve
115 B (Item E)
30
CNG限压阀
CNG Regulator
115 B (Item E)
31
油气混合器
Gas Air Mixture
115 B (Item E)
32
汽油磁阀
Petrol solenoid valve
115 B (Item E)
33
CNG磁阀
CNG solenoid Valve
115 B (Item E)
34
高压管
High pressure tube
115 B (Item E)
35
低压管
Low pressure tube
115 B (Item E)
36
线束
Wiring Harness
115 B (Item E)
37
硬橡胶垫
Hard rubber for cylinder mounting
115 B (Item E)
38
限流装置(保险丝)
Current limiting device (fuse)
115 B (Item E)
39
压力指示器
Pressure indicator
115 B (Item E)
40
电缆及保险丝
Electrical Cables & Fuses
-
41
端子、连接器及元件
Terminals, Connectors & Elements
-
42
电气装置及布线
Safety Requirements of electrical equipments & wiring
-
43
电路图
Type Approval of circuit diagram
-
44
导线导体
Electrical Conductor Test
-
45
照明
Illumination
-

大巴ARAI
M3 Category - A Motor vehicle used for carriage of passengers, comprising nine or more seats in addition to driver's seat and having a gross vehicle weight exceeding five tonnes.
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
定义
Definitions (Classification of the Vehicle) – M3
2
2
电动车CMVR型式批准程序
CMVR type approval for battery operated vehicles
-
3
功能及安全测试(电动车)
Functional and safety tests (Electric Vehicles)
124(1)26 (a)
4
电能消耗(电动车)
Measurement of electric energy consumption test (Electric Vehicles)
124 (1) 27
5
续驶里程(电动车)
Range test (Electric Vehicles)
124 (1) 28
6

最大及30分钟功率
Measurement of Max power and 30 min power
124 (1) 29
7
拍照存档
Photographs
-
8
CMVR物理检查项
CMVR physical verifications
93 to 125
9
车重
Vehicle weighment
95
10
制动
Brake test
96(4)
11
防抱死系统ABS Testing96 (5)(6)(7)(a)& (8)
12
通过噪音Pass by noise test120(2)
13
内部噪音Interior noise test124 (1)(40)
14
滑行测试
Coast down test
-
15
电磁兼容
Electromagnetic compatibility of motor vehicle
124(1) (21) (ii)
16
限速装置
Speed governor
118 (1)
17
加速控制装置
Accelerator control system
124(1) (15)
18
仪表盘标识
Tell tale symbols
124(1) (19)
19
灯具安装
Installation requirements for Lighting & Signaling
124(1) (20)
20
前照灯调节装置
Vertical orientation for dipped beam - head lamp
124(1) (20)
21
爬坡
Gradeability test
124(1) (23)
22
防火
Flammability requirement
124 (1) (37)
23
雨刮
Windscreen wiping system
101(2) (3)
24
扶手
Hand hold
124 (1) (42)
25
防盗
Protective devices against unauthorized use for M
124 (1) (51)
26
转弯半径
Turning circle diameter test
98(2)
27
转向力
Steering effort test
98(3)
28
车速表
Speedometer calibration
117(1)(2)
29
外部突出物
External projection test
124(11)
30
等速油耗
Constant speed fuel consumption
124(1) (31)
31
喇叭安装
Horn Installation
119(1)
32
后视镜安装
Rear View Mirror Installation
125(2)
33
车架号及发动机号刻印
Embossment of the Chassis Number & Engine
122(1)
34
反光条安装
Fitment of Reflective tape
104(1)
35
临时驾驶室
Temporary Cabin fitted on drive away chassis
125(1-C)
36
内饰
Interior Fittings
124(38)
37
后防护
Rear Under Run Protection Device
124(1A)
38
侧防护
Vehicle Lateral Protection Side
124(1A)
39
轮栓、轮盘及轮毂罩
Wheel nuts , wheel discs & hub caps
124(14)
40
大巴车窗
Bus window retention
124(1) (12)
41
大巴车身生产商授权
Accreditation of Bus Body Builders
125C (1)
42
尺寸检查-大巴车身
Dimesnional Verification- Vehicle as per bus body
125C (1)
43
物理检查项 - 电平测试
Physical Verification- Electrical Level Tests
125C (1)
44
车身结构稳定性
Body Structure Stability (as per 6.2)
125C (1)
45
车身结构计算机模拟测试
Body Structure Strength Test using Computer (as per 6.1) (Including Joint Strength Tests)
125C (1)
46
雨刮模拟测试
Wiping Test on Mockup
101(2) (3)
47
座椅固定点
Seat Anchorage Test
AIS 023
48
内部振动
Interior Vibration
125 (C) (7)
49
内部声振粗糙度
Interior Harshness
125 (C) (7)
50
加速
Acceleration
125 (C) (7)
51
最低固有频率
Lowest Natural frequency
125 (C) (7) (a)
52
物理检查项(AIS 153)
Physical Verification (AIS 153)
125 (C) (7)
53
火灾探测报警及火灾探测灭火系统
FDAS/FDSS (vehicle level)
125 (C) (7)
54
轮椅约束系统
Wheel chair restraint system
125 (C) (7) (a)
55
应急照明系统
Emergency Lighting System
125 (C) (7)
56
电动坡
Power Operated Ramps
125 (C) (7)
57
制动及车辆稳定性
Braking Performance & Vehicle Stability Function
125 (C) (7)
58
车辆定位跟踪系统
Vehicle Tracking System
125 H (1, 2)
59
冷却性能
Cooling Perfomance test
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
座椅、固定点及头枕
Seat, their Anchorages & Head Restraints
125 (6)
a
驾驶座椅
Driver Seat
125 (6)
b
副驾驶座椅
Co-Driver Seat
125 (6)
c
乘客座椅
Passenger Seat
125 (6)
2
门锁门铰链
Door Lock/Door rentention
124 (1)Table
3
安全玻璃
Safety Glass
100 (2)
4
后视镜(外部)
Rear view Mirror (Exterior)
125(2)
5
安全带
Safety Belt Assemblies
125 (1)
6
安全带固定点
Safety Belt Anchorages
125 (1)
7
车窗
Window Frame
-
8
车窗固定及开启
Window Retention & release
-
9
雨刮系统及雨刮片
Windscreen Wiping System & Wiper Blade
101 (2)
10
衬料
Safety requirements of Pad Material
-
11
填料
Safety requirements of Upholstery
-
12
防火
Flammability requirement (For 22 seater above)
-
13
轮毂
Wheel Rims
124(8)
14
轮胎
Tyres
95
15
尘土雨水进入
Ingress of Dust & Rain water
-
16
车身绝缘
Safety requirements of Body Insulation
-
17
空调系统
Safety requirements of AC System
-
18
回复反射器
Reflex Reflectors
104 (4)
19
火灾探测报警系统及火灾探测灭火系统
Fire Detection & Alarm System (FDAS) & Fire detection & suppression system (FDSS) - Component level
125 (C) (7) (a)
20
喇叭
Automotive Horns
119 (1)
21
灯具
Performance Requirements for Lighting & Signaling
124 (1)
22
三角警告牌
Warning Triangles
138 (1A)
23
反射条粘贴
Fitment of reflective tape
104(1)
24
车辆定位追踪单元
Vehicle tracking Unit
125 H
25
电缆及保险丝
Electrical Cables & Fuses
-
26
端子、连接器及元件
Terminals, Connectors & Elements
-
27
电气装置及布线
Safety Requirements of electrical equipments & wiring
-
28
动力电池
Traction Batteries for BOV
-
29
电路图
Type Approval of circuit diagram
-
30
导线导体
Electrical Conductor Test
-
31
照明
Illumination
-

大巴ARAI
M3 Category - A Motor vehicle used for carriage of passengers, comprising nine or more seats in addition to driver's seat and having a gross vehicle weight exceeding five tonnes.
整车技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
定义
Definitions (Classification of the Vehicle) – M3
2
2
电动车CMVR型式批准程序
CMVR type approval for battery operated vehicles
-
3
功能及安全测试(电动车)
Functional and safety tests (Electric Vehicles)
124(1)26 (a)
4
电能消耗(电动车)
Measurement of electric energy consumption test (Electric Vehicles)
124 (1) 27
5
续驶里程(电动车)
Range test (Electric Vehicles)
124 (1) 28
6

最大及30分钟功率
Measurement of Max power and 30 min power
124 (1) 29
7
拍照存档
Photographs
-
8
CMVR物理检查项
CMVR physical verifications
93 to 125
9
车重
Vehicle weighment
95
10
制动
Brake test
96(4)
11
防抱死系统ABS Testing96 (5)(6)(7)(a)& (8)
12
通过噪音Pass by noise test120(2)
13
内部噪音Interior noise test124 (1)(40)
14
滑行测试
Coast down test
-
15
电磁兼容
Electromagnetic compatibility of motor vehicle
124(1) (21) (ii)
16
限速装置
Speed governor
118 (1)
17
加速控制装置
Accelerator control system
124(1) (15)
18
仪表盘标识
Tell tale symbols
124(1) (19)
19
灯具安装
Installation requirements for Lighting & Signaling
124(1) (20)
20
前照灯调节装置
Vertical orientation for dipped beam - head lamp
124(1) (20)
21
爬坡
Gradeability test
124(1) (23)
22
防火
Flammability requirement
124 (1) (37)
23
雨刮
Windscreen wiping system
101(2) (3)
24
扶手
Hand hold
124 (1) (42)
25
防盗
Protective devices against unauthorized use for M
124 (1) (51)
26
转弯半径
Turning circle diameter test
98(2)
27
转向力
Steering effort test
98(3)
28
车速表
Speedometer calibration
117(1)(2)
29
外部突出物
External projection test
124(11)
30
等速油耗
Constant speed fuel consumption
124(1) (31)
31
喇叭安装
Horn Installation
119(1)
32
后视镜安装
Rear View Mirror Installation
125(2)
33
车架号及发动机号刻印
Embossment of the Chassis Number & Engine
122(1)
34
反光条安装
Fitment of Reflective tape
104(1)
35
颗粒物排放
Engine mass emission with particulate
115
36
排放(OBD II)
On-board Diagnostic System (OBD II) for Emission
115
37
自由加速测试(烟度)
Free acceleration test (Maximum smoke density)
115
38
排放(BS VI)
Engine Mass Emission (BS VI norms)
115
39
发动机功率
Engine Power test
115
40
临时驾驶室
Temporary Cabin fitted on drive away chassis
125(1-C)
41
内饰
Interior Fittings
124(38)
42
后防护
Rear Under Run Protection Device
124(1A)
43
侧防护
Vehicle Lateral Protection Side
124(1A)
44
轮栓、轮盘及轮毂罩
Wheel nuts , wheel discs & hub caps
124(14)
45
大巴车窗
Bus window retention
124(1) (12)
46
大巴车身生产商授权
Accreditation of Bus Body Builders
125C (1)
47
尺寸检查-大巴车身
Dimesnional Verification- Vehicle as per bus body
125C (1)
48
物理检查项 - 电平测试
Physical Verification- Electrical Level Tests
125C (1)
49
车身结构稳定性
Body Structure Stability (as per 6.2)
125C (1)
50
车身结构计算机模拟测试
Body Structure Strength Test using Computer (as per 6.1) (Including Joint Strength Tests)
125C (1)
51
雨刮模拟测试
Wiping Test on Mockup
101(2) (3)
52
座椅固定点
Seat Anchorage Test
AIS 023
53
内部振动
Interior Vibration
125 (C) (7)
54
内部声振粗糙度
Interior Harshness
125 (C) (7)
55
加速
Acceleration
125 (C) (7)
56
最低固有频率
Lowest Natural frequency
125 (C) (7) (a)
57
物理检查项(AIS 153)
Physical Verification (AIS 153)
125 (C) (7)
58
火灾探测报警及火灾探测灭火系统
FDAS/FDSS (vehicle level)
125 (C) (7)
59
轮椅约束系统
Wheel chair restraint system
125 (C) (7) (a)
60
应急照明系统
Emergency Lighting System
125 (C) (7)
61
电动坡
Power Operated Ramps
125 (C) (7)
62
制动及车辆稳定性
Braking Performance & Vehicle Stability Function
125 (C) (7)
63
实际驾驶排放
Real Driving Emmisions (RDE)
115
64
车辆定位跟踪系统
Vehicle Tracking System
125 H (1, 2)
65
冷却性能
Cooling Perfomance test
-




零部件技术要求
序号
测试项目(中文)
测试项目(英文)
CMVR法规号
1
座椅、固定点及头枕
Seat, their Anchorages & Head Restraints
125 (6)
a
驾驶座椅
Driver Seat
125 (6)
b
副驾驶座椅
Co-Driver Seat
125 (6)
c
乘客座椅
Passenger Seat
125 (6)
2
门锁门铰链
Door Lock/Door rentention
124 (1)Table
3
安全玻璃
Safety Glass
100 (2)
4
后视镜(外部)
Rear view Mirror (Exterior)
125(2)
5
安全带
Safety Belt Assemblies
125 (1)
6
安全带固定点
Safety Belt Anchorages
125 (1)
7
车窗
Window Frame
-
8
车窗固定及开启
Window Retention & release
-
9
雨刮系统及雨刮片
Windscreen Wiping System & Wiper Blade
101 (2)
10
衬料
Safety requirements of Pad Material
-
11
填料
Safety requirements of Upholstery
-
12
防火
Flammability requirement (For 22 seater above)
-
13
轮毂
Wheel Rims
124(8)
14
轮胎
Tyres
95
15
尘土雨水进入
